Coemar StageLite LED FX RGBW

Call for price

The light beam is generated by three motorized and independent optical planes with a total of 96 RGBW LED chip (24 per color) 1.2 watt each. Symmetric and asymmetric beam in one single fixture: StageLite Led FX is a truly unique fixture which can be focused asymmetrically on a cyclorama, used as a foot wash, up lit, or used for effects. The vertical beam zoom from 11° to 34° can be also focused from +56° to -52°. The three different LED bars are divided into two cells and can be individually controlled (both mechanically and optically). The three-bar lens is completely customizable to allow a perfect spread and focus of the beam.
Categories: , , , , , , Tags: , ,

Description

Features

  • RGB+W color mixing
  • The light beam is generated by three independent optical planes with 3 different types of customized lenses (13° x 40° lenses mounted)
  • 4 different control modes: global (compact), 2 zones (cell), 3 lines (lines), 6 ½ lines (frames)
  • Intensity of each ½ line of LEDs can be individually controlled
  • Orientable beam from +56° to -52° and linear adjustment with digital positioning control: concentrate, symmetrical or asymmetrical
  • Proportional zoom from 11° to 34° (vertical beam, ½ peak angle)
  • Electronic dimmer
  • Synchronized, random or pulse electronic strobe
  • Swing effects
  • Guaranteed flicker-free operation with LEDs frequency controlled via DMX from 500 to 5.000 Hz
  • Quick cam-lock clamps, on a modular guide with adjustable position
  • IP rating: 20 or 65 (weatherproof)
  • CE approved

Light Source

  • 96 Cree LEDs (24 Red, 24 Green, 24 Blue, and 24 White – 6.500 K).
  • Average LED lifetime: a minimum of 80% of the initial luminous flux will be maintained after approx. 50.000 hours of usage (50.000 LM80).

Control protocol and programming

  • USITT DMX512A
  • DMX channels: 32 / 20 / 16 / 12
  • Setting, addressing, testing and measurements via LEDs display or remotely with Dr1+ Plus
  • RDM (Remote Device Management)

Connections and electrical specifications

  • AC power: 90-264 V, auto-sensing, 50/60 Hz, 2m (6.6 ft) integral cable without power plug, with PowerCon connector (only IP 20 version)
  • Max power consumption: 210 W
  • Power consumption: 1 A at 230 V, 2 A at 115 V – cosφ 0,9
  • DMX data in/out: 5 pin locking XLR

Physical size

  • Length: 609.6 mm (24 in)
  • Width: 210.6 mm (8.3 in)
  • Height: 181.3 mm (7.1 in) – with mounting bracket: 341.1 mm (13.4 in)
  • Weight: 12 kg (26.4 lbs)

Accessories

  • 2 ground-standing feet
